Dukane ImagePro 6540 Projector

XGA Conference Room Projector
Calculate Throw Distance

The Dukane ImagePro 6540 Projector is a XGA Conference Room Projector. This lamp based projector is capable of displaying 4,000 Lumens at its brightest setting with a native resolution of 1024x768 , and is 3D capable. The internal DLP technology touts higher contrast, less visible pixels and more portability. This projector was first available for purchase in May 2014 and has been by Dukane. The Dukane ImagePro 6540 projector was manufactured by NEC as the NP-M402X.



Dukane ImagePro 6540 Projector Specifications


MSRP
$2,115
Status
Discontinued
Released
May 2014
Warranty
5 Years
User Reviews
Review this Projector

Switch to Metric
Brightness
4,000 ANSI Lumens
Resolution
1024x768
Aspect Ratio
4:3 (XGA)
Contrast
10,000:1
Display Type
0.55" DLP x 1
Color Processing
8-bit
Video Modes
720p, 1080i, 1080p/60, 576i, 576p, 480p, 480i
Data Modes
MAX 1920x1200
3D Modes
PC 3D Ready

Lamp Type
270W AC bulb
Lamp Life
3,500 hours  / 8,000 hours
Lamp Model
456-6540 / NP30LP  Buy Replacement Lamp

Included Lens
1.7x manual zoom , manual focus
Optional Lenses
No
Lens Shift
No
Throw Distance
5.0' - 30.0'  Calculate Throw Distance
Image Size
30.00" - 300.00"
Throw Ratio
1.50:1 - 2.50:1
Projector Placement
For a
"
diagonal screen, place the projector lens between 10'-0" and 16'-8" from the screen.
Digital Keystone
Horizontal & Vertical

Projector Size
3.50" x 13.40" x 10.10"
Weight
7.7 lbs
Audible Noise
39 dB  / 33 dB
Internal Speakers
20.0 Watts Mono
Power
335 Watts 100V - 240V
Connection Panel
Composite: RCA
HDMI x 2
Network: RJ-45
RS232: DB-9pin
S-Video
USB
VGA In: Dsub-15pin

Features
PC 3D Ready
Closed Captioning
DICOM
Blackboard Mode
Crestron RoomView™
Additional Features
USB Viewer allows you to present without a PC using a USB flash drive
