The Dukane ImagePro 6540HD Projector is a 1080P Conference Room Projector. This lamp based projector is capable of displaying 4,000 Lumens at its brightest setting with a native resolution of 1920x1080 . The internal DLP technology touts higher contrast, less visible pixels and more portability. This projector was first available for purchase in December 2014 and has been by Dukane. The Dukane ImagePro 6540HD projector was manufactured by NEC as the NP-M402H.
Product Downloads
Helpful Links
Buy a Lamp
Get a Repair
Get a Screen
Buy LocalDukane ImagePro 6540HD Projector Specifications
- MSRP
- $3,239
- Brightness
- 4,000 Lumens (ANSI)1
- Resolution
- 1920x1080
- Aspect Ratio
- 16:9 (HD)
- Contrast
- 10,000:1
- Display Type
- 0.65" DLP x 1
- Color Processing
- 8-bit
- Video Modes
- 1080i, 1080p/60, 576i, 576p, 480p, 480i
- Data Modes
- MAX 1920x1200
- Light Source
- 270W AC bulb
- Light Source Life
- 3,500 hours / 8,000 hours
- Lamp Model
- NP30LP Buy NP30LP Lamp
- Included Lens
- 1.7x manual zoom , manual focus
- Optional Lenses
- No
- Throw Distance
- 2.4' - 46.2' Calculate Throw Distance
- Image Size
- 16.52" - 530.07"
- Throw Ratio
- 1.20:1 - 2.00:1
- Digital Keystone
- Horizontal & Vertical
- Projector Size
- 4.30" x 14.50" x 11.50"
- Weight
- 8.2 lbs
- Audible Noise
- 39 dB / 33 dB
- Internal Speakers
- 20.0 Watts Mono
- Power
- 354 Watts 100V - 240V
- Connection Panel
-
Composite: RCAHDMI x 2Network: RJ-45RS232: DB-9pinUSBVGA In: Dsub-15pin
- Features
-
Closed CaptioningDICOMBlackboard ModeSoft Carrying CaseCrestron RoomView™
- Additional Features
- The 6540WU offers lamp life up to 8,000 hours and a high contrast ratio of up to 10,000:1, while Crestron Roomview aids in emergency messaging.
